8.2.2 Process input data – analog modules
TBEN-S2-4AI
Word no. Bit no.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Inputs
MSB LSB
0x0000 Analog value channel 0
0x0001 Analog value channel 1
0x0002 Analog value channel 2
0x0003 Analog value channel 3
Diagnostics
0x0004 Channel 1 Channel 0
LLVU UFL OFL WBR V1
AOL
ULVE RTDSC CJE LLVU UFL OFL WBR V1
AOL
ULVE RTDSC CJE
0x0005 Channel 3 Channel 2
LLVU UFL OFL WBR V1
AOL
ULVE RTDSC CJE LLVU UFL OFL WBR V1
AOL
ULVE RTDSC CJE
Module status
0x0006 - FCE - - - COM V1 - - - - - - - ARGEE Diag
Warn
TBEN-S2-4AO
Word no. Bit no.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Diagnostics
0x0000 Channel 1 Channel 0
- - - - - - WBR OVL - - - - - - WBR OVL
0x0001 Channel 3 Channel 2
- - - - - - WBR OVL - - - - - - WBR OVL
Module status
0x0002 - FCE - - - COM V1 - - - - - - - ARGEE Diag
Warn
Meaning of the process data bits
Name Meaning
CJE Cold junction error The measured temperature exceeds the nom-
inal range for more than 1 % or wrong config-
uration of the cold junction compensation. In
case of an error, a cold junction temperature of
25 °C is assumed.
