Parameterizing and Configuring
Configuring the devices at EtherNet/IP
110
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
8.8.6 EtherNet/IP standard classes
The modules support the following EtherNet/IP standard classes in accordance with the CIP
specification.
Class code Object name
Dec. Hex.
01 0x01 Identity Object [}110]
04 0x04 Assembly Object [}111]
06 0x06 Connection Manager Object [}134]
245 0xF5 TCP/IP Interface Object [}135]
246 0xF6 Ethernet Link Object [}138]
Identity Object (0x01)
The following description of the Ethernet Link Object is taken from the CIP specification, Vol. 2,
Rev. 2.1 by ODVA & ControlNet International Ltd. and adapted to the Turck products.
Instance attributes
Attribute no. Attribute
name
Get/set Type Value
Dec. Hex.
1 0x01 Vendor ID G UINT Contains the manufacturer ID.
Turck = 0x46
2 0x02 Product
type
G UINT Shows the general product type.
Communications Adapter 12
dez
=
0x0C
3 0x03 Product
code
G UINT Identifies a special product in a
device type.
default: 27247
dec
= 6A6F
4 0x04 Revision
n Major
n Minor
G STRUCT OF:
n USINT
n USINT
Revision of the device which is rep-
resented by the Indentity Object.
n 0x01
n 0x06
5 0x05 Device
status
G WORD WORD
6 0x06 Serial
number
G UDINT Contains the identification number
of the product (the last 3 bytes of the
MAC-ID).
7 0x07 Product
name
G STRUCT OF:
USINT
STRING [13]
i.e.: TBEN-S2-4IOL
Device Status
Bit Name Definition
0…1 reserved default = 0
2 Configured TRUE = 1:
The application in the device has been con-
figured (default setting).
3 reserved default = 0
