Parameterizing and Configuring
Configuring the devices at EtherNet/IP
138
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
Ethernet Link Object (0xF6)
The following description of the Ethernet Link Object is taken from the CIP specification, Vol. 2,
Rev. 1.1 by ODVA & ControlNet International Ltd. and adapted to the Turck products.
Class attributes
Attr.-no. Designation Get/Set Type Value
Dec. Hex.
1 0x01 Revision G UINT 1
2 0x02 Max. object instance G UINT 1
3 0x03 Number of instances G UINT 1
6 0x06 Max. class identifier G UINT 7
7 0x07 Max. instance attribute G UINT 6
Instance attributes
Attr.-no. Designation Get/Set Type Value
Dec. Hex.
1 0x01 Interface speed G UDINT Speed in megabit per
second (e.g. (z. B. 10, 100,
1000 etc.)
2 0x02 Interface flags G DWORD Interface capability flag
3 0x03 Physical address G ARRAY OF
USINT
Contains the interface’s
MAC address (Turck:
00:07:46:xx:xx:xx)
6 0x06 Interface control G 2 WORD Allows port-wise changes
of the Ethernet-settings
7 0x07 Interface type G
10 0x0A Interface label G
Interface flags
Bit Designation Meaning Default value
0 Link status Indicates whether or not the Ethernet communica-
tions interface is connected to an active network.
0 = inactive link
1 = active link
Depends on
application
1 Half/full duplex 0 = Half duplex
1 = Full duplex
If the Link Status flag is 0, the value of the Half/Full
Duplex flag is indeterminate.
Depends on
application
2…4 Negotiation
status
Indicates the status of the automatic autonegoti-
ation
0 = autonegotiation in progress
1 = autonegotiation and speed detection failed, Us-
ing default values for speed and duplex (10Mbps/
half duplex).
2 = auto-negotiation failed but detected speed (de-
fault: half duplex).
3 = successfully negotiated speed and duplex
4 = Autonegotiation not started, yet Forced speed
and duplex.
Depends on
application
