Parameterizing and Configuring
Configuring the devices at EtherNet/IP
114
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
n Configuration Assembly – TBEN-S2-8DIP
Byte no. Bit no.
Dec. Hex. 7 6 5 4 3 2 1 0
Device Configuration Data [}112]
0…9 0x00…
0x09
- Eth2 Port-
Setup
Eth1 Port-
Setup
Quick
Connect
Parameter data [}39]
Channel 0
10 0x0A DMOD_CNT DI0
11 0x0B - - - - - - - DIFT DI0
12 0x0C IST DI0
13 0x0D -
Channel 1
14 0x0E DMOD DI1
15 0x0F - - - - - - - DIFT DI1
16 0x10 IST DI1
17 0x11 -
Channel 2
18 0x12 Assignment similar to channel 1 (byte 14…17)
19 0x13
20 0x14
21 0x15
…
Channel 7
38 0x26 Assignment similar to channel 1 (byte 14…17)
39 0x27
40 0x28
41 0x29
42 0x2A - - - - - - VAUX1 pin1 C0 (Ch0/1)
43 0x2B - - - - - - VAUX1 pin1 C1 (Ch2/3)
44 0x2C - - - - - - VAUX1 pin1 C2 (Ch4/5)
45 0x2D - - - - - - VAUX1 pin1 C3 (Ch6/7)
