Product Description
Possible Ethernet network structures
16
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
SE-84X-E924
9-Port Industrial Ethernet Switch
Power
10/100 Act/Link
Uplink Port
1 = 2 = 3 = N/C 4 = 5 =
N/C (- Voltage) (+ Voltage) N/C
10/100 Act/Link Act/LinkAct/Link 10/100
1
2
3
4 5
Power Port
10-30 VDC
OFFLED
10 Mbits10/100
Act/Link No Link
ON
100 Mbits
Linked
Blink
--------
Activity
10/10010/100 Act/Link
10/100 Act/Link Act/LinkAct/Link 10/100 10/10010/100 Act/Link
PLC/HMI Service/Engineering
24 VDC
Ethernet
Fig.6: Network structure, example 2
