turck TBEN-S2 User Manual

V04.00 | 2021/05
41
Parameter name Value Meaning Description
Dec. Hex.
10 0x0A Ni1000, -60…250 °C, -76…482 °F
11 0x0B Ni1000, -60…150 °C, -76…302 °F
RTDW
T
RTD wiring type
0 0x00 2-wire
1 0x01 3-wire
2 0x02 4-wire
RWT Resistance wiring
type
0 0x00 2-wire
1 0x01 3-wire
2 0x02 4-wire
SUP Mains suppression
0 0x00 Off
1 0x01
50 Hz
2 0x02 60 Hz
TCCC
J
Thermocouple cold
junction compens-
ation
0 0x00 Pt1000
A Pt100 serves as cold junction.
1 0x01 Pt100 A Pt100 serves as cold junction.
2 0x02 Cold junction of channel
0
The value determined for channel 0 is
taken as cold junction.
3 0x03 None No cold junction compensation
TCT Thermocouple type
0 0x00 Type K, -270…1370 °C, -454…2498 °F
1 0x01 Type B, 100…1820 °C, 212…3308 °F
2 0x02 Type E, -270…1000 °C, -454…1832 °F
3 0x03 Type J, -210…1200 °C, -346…2192 °F
4 0x04 Type N, -270…1300 °C, -454…2372 °F
5 0x05 Type R, -50…1768 °C, -58…3214 °F
6 0x06 Type S, -50…1768 °C, -58…3214 °F
7 0x07 Type T, -270…400 °C, -454…752 °F
8 0x08 Type C, 0…2315 °C, 32…4199 °F
9 0x09 Type G, 0…2315 °C, 32…4199 °F
TMU Temperature unit
0 0x00 Celsius
1 0x01 Fahrenheit
UMR Voltage range
0 0x00 -10…10 V
1 0x01 0…10 V
2 0x02 2…10 V
3 0x03 0…5 V
4 0x04 1…5 V
5 0x05 -1…1 V
6 0x06 -500…500 mV
7 0x07 -100…100 mV
8 0x08 -50…50 mV
VWT Voltage wiring type
0 0x00 Differential
Differential input
1 0x01 Single ended Connection of sensors with common
ground [}33]
2 0x02 differential without
ground
Differential input
