Parameterizing and Configuring
Process input data – overview
46
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
TBEN-S1-8DOP
Word no. Bit no.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Diagnostics
0x0000 ERR7 ERR6 ERR5 ERR4 ERR3 ERR2 ERR1 ERR0 - - - - - - VERR
V2
Ch4-7
VERR
V2
Ch0-3
PWM Diagnostics Ch3
0x0001 - - - - - - - - - - - - - - PWM OUT ERR
DO3
PWM Diagnostics Ch7
0x0002 - - - - - - - - - - - - - - PWM OUT ERR
DO7
Module status
0x0003 - FCE - - - COM V1 - - - - - - - ARGEE Diag
Warn
TBEN-S1-4DIP-4DOP
Word no. Bit no.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Inputs
0x0000 - - - - - - - - - - - - DI3
C3P4
DI2
C2P4
DI1
C1P4
DI0
C0P4
Diagnostics
0x0001 - - - - ERR3 ERR2 ERR1 ERR0 - - - - - - VERR
V1
Ch4-7
VERR
V1
Ch0-3
Latch input
0x0002 - - - - - - - - - - - - DI3 DI2 DI1 DI0
Counter Ch0
0x0003 Counter value LSB
0x0004 Counter value MSB
Frequency Ch0
0x0005 Frequency MSB Frequency LSB
Status
0x0006 -
PWM Diagnostics Ch7
0x0007 - - - - - - - - - - - - - - PWM OUT ERR
DO7
Module status
0x0008 - FCE - - - COM V1 - - - - - - - ARGEE Diag
Warn
