Parameterizing and Configuring
Configuring devices at Modbus TCP
78
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
TBEN-S1-8DIP-D – output registers
Meaning of the process output data [}53]
Register no. Bit no.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Latch reset
0x0800 - - - - - - - - DI7 DI6 DI5 DI4 DI3 DI2 DI1 DI0
Counter reset
0x0801 - - - - - - - - - - - - - - - CNT
reset
TBEN-S1-8DIP-D – parameter registers
Parameter description [}39]
Register no. Bit no.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Channel 0
0xB000 IST DI0 DIFT DI0 DMOD_CNT DI0
Channel 1
0xB001 IST DI1 DIFT DI1 DMOD DI1
…
Channel 7
0xB007 IST DI7 DIFT DI7 DMOD DI7
