998-2300 Rev. H Page 32
• Logged data has the following fields:
2
Channel names and units are logged as per the C3 setup form and not C-soft. These can be
changed during a logging session but it is not recommended.
FieldName Example Notes
C3_Date 11/22/10 Current C3 Date
C3_Time 10:21:14 Current C3 Time
C3_DepthM 9.66 C3 Depth in Meters
C3_DegC 19.38 C3 Temperature in degrees Celsius
Chan1_Val 6.56 Channel 1 value
Chan1_Unit PPB
2
Channel 1 Units (from C3 Setup Form. Not C-Soft)
Chan1_Type Rhodamine Channel 1 Name (from C3 Setup Form. Not C-Soft)
Chan2_Val 11.12 Channel 2 value
Chan2_Unit NTU Channel 2 Units (from C3 Setup Form. Not C-Soft)
Chan2_Type Turbidity Channel 2 Name (from C3 Setup Form. Not C-Soft)
Chan3_Val 7.68 Channel 3 value
Chan3_Unit µg/l Channel 3 Units (from C3 Setup Form. Not C-Soft)
Chan3_Type Chlorophyll a Channel 3 Name (from C3 Setup Form. Not C-Soft)
Lat_DD -41.22914167 Latitude in Decimal degrees (Southern Latitudes negative)
Long_DD 173.0817033 Longitude in Degrees (Western Longitudes negative)
COG_True 17.58 Course over ground in degrees true
SOG 5.5556 Speed over ground in GPS Display Options Speed Units
SOG_Unit Meters/Sec GPS Speed over Ground Units
UTC_Date 21/11/2010 GPS date (in UTC)
UTC_Time 21:19:16 GPS Time (in UTC)
Flag -1 Flag value (0 = no flag ; -1 = Flagged)
Flag_Notes Start Transect 1 Flag Notes
