Property Dimension
Tray dimensions ~16.6" x~8.1"x~0.8" (42.1cm x 20.7cm x2.05cm)
No. of trays 5
Net weight ~124lbs (56kg)
Shipping weight ~152lbs (69kg)
Floor loading requirements ~165 lbs(75kg).
Mineral-free
water
reservoir
Max. water
volume
Overflow (up to the float) – ~155 Ounces
(4.6lit)
Min. water
volume
~33.8 Ounces (1lit)
The volume used
by the sterilization
cycle/load having
the highest steam
consumption
Recorded ~30 Ounces (~900ml) for "Wrapped
273F" + Virus Protect
Used (waste)
water
reservoir
Max. water
volume
Max vol. –./~135 Ounces /(4.0 lit)
Float – ~125 Ounces (3.7lit.) max allowed for start
cycle
Safety relief valve ~40 PSI (2.8 bar)
Load No. counter Counting from 0 to 999 and nullifies.
Page 11
