The perforation between pages should not extend all the
way to the edges of the paper.
At the perforation between pages, the horizontal and
vertical perforation cuts should not cross.
The thickness of the perforation part when extended
should be 1 mm or less.
Continuous paper
with labels: Front and Bottom entry
Label size 23.8 x 63.5 mm (15/16 x 2.5”)
Minimum 2.5 mm (0.1)
cornerradius, minimum
Backing sheet width 101.6 to 254 mm (4.0 to 10.0)
Backing sheet length 101.6 to 558.8 mm (4.0 to 22.0)
(one page)
Backing sheet thickness 0.07 to 0.09 mm (0.0028 to 0.0035)
Total thickness 0.16 to 0.19 mm (0.0063 to 0.0075)
Label weight 64 g/m2 (17 lb)
Roll Paper
Feed Type Rear entry with std roll paper holder
Width 2.7 to 8.0”
Paper Roll Diameter 8.5 mm max
Roll Paper Type Std, 1+1 (multi-part)
Thickness 0.07 to 0.09 mm (0.0028 to 0.0035”)
Weight 52 to 82 g / m2 (14 to 22 lb)
61
