TVS WEGO 110 - Page 10

10
KNOW YOUR TVS WEGO
KNOW YOUR TVS WEGO
HANDLE BAR For WEGO Refresh
* Applicable for select variant only
** Applicable only for disc brake model
1. Glove box lock*
2. Bag hook (front)
3. Choke knob
4. Horn switch
5. Turn signal lamp switch
6. Rear brake lever
7. Parking brake (rear brake lock)
8. Rear view mirror L
9. High / low beam switch
10. Full digital speedometer
11. Rear view mirror R
12. Brake fluid inspection window**
13. Front brake lever
14. Throttle grip
15. Lights switch (ON/OFF)
16. Electric starter switch
17. Ignition cum steering lock
1
8
9 11
12
13
14
15
16
17
10
2
5
3
6
4
7
