47
MAINTENANCE
MAINTENANCE
Tyre rotation direction
While reassembling the tyres, after removing from the
wheel rim, ensure that the arrow mark ‘FRONT’ facing
the direction of wheel rotation while fixing the tyre on
the front wheel rim. Similarly, arrow mark ‘REAR’ on
the tyre facing the direction of wheel rotation while
fixing the tyre on the rear wheel rim.
Tyre puncture
Your scooter is fitted with a tubeless tyre on both front
and rear wheel. Incase of any puncture / tyre damage,
it is advised to visit the nearest tyre manufacturer
Dealer or the tyre repair shops who knows the
repairing method of tubeless tyre. It is not necessary
to remove the tyre from wheel rim always to attend a
puncture.
Caution
Side walls of the tubeless tyre which in contact with the wheel
rim are only seals the air inside the wheel assembly. Hence
care should be taken not to damage the side walls of the tyres
during removal / reassembly.
If there is a need for tyre removal, it is strongly
recommended to use a tyre removal / fitment
machine. If at all tyre levers needs to be used, the
levers should be free from sharp edges. Care should
be taken not to damage the tyres and rims.
FRONT WHEEL REMOVAL
Drum brake
1. Remove the axle nut (1) along with a washer.
2. Pull out the axle (2) along with a washer and take
out a spacer from the right side of the wheel.
1
2
