54
TECHNICAL SPECIFICATIONS
TECHNICAL SPECIFICATIONS
MANUFACTURER : TVS MOTOR COMPANY LIMITED
P.B. No 4, Harita, Hosur - 635 109, India.
ENGINE
Type : S i n g l e c y l i n d e r , 4
stroke, air cooled, spark
ignition engine
Cylinder bore : 53.5 mm
Stroke : 48.8 mm
Piston displacement : 109.7 cc
Compression ratio : 9.3 : 1*
9.5 : 1**
Carburettor : UCAL VM 16 SH
Air filter : Double polyurethane
foam filter element*
Viscous paper filter**
Lubrication system : Forced wet sump
Maximum power in kW : 5.88 @ 7500 rpm
Maximum torque in Nm : 8.0 @ 5500 rpm*
8.4 @ 5500 rpm**
Maximum speed : Around 78 km / hr
Engine idling rpm*** : 1600 + 100 rpm
Starting system : Electric starter / kick
starter
TRANSMISSION
Clutch : Dry - Centrifugal clutch
Primary transmission : CVT (Continuous
Variomatic Transmission)
Primary reduction : 2.2 to 0.88*
2.38 to 0.82**
Final reduction : 10.47
CHASSIS
Dimensions and weights
Overall length : 1834 mm
Overall width : 640 mm
Overall height : 1115 mm
Ground clearance : 132 mm
Wheel base : 1275 mm
* TVS WEGO Drum & Disc versions
** TVS WEGO Refresh version
*** Under warm condition
