15
KNOW YOUR TVS WEGO
KNOW YOUR TVS WEGO
Never attempt to move the vehicle when the steering is locked,
you may lose balance.
When the ignition lock is turned ‘ON’, the speedometer
performs self test and the back light of the speedometer glows
continuously. Wait till the self test cycle of speedometer gets
over.
Warning
Note
2
1
3
4
5
6
SPEEDOMETER ASSEMBLY
1. Fuel gauge
Fuel gauge indicates the approximate quantity of fuel
available in the fuel tank. Fill fuel as soon as possible
when the fuel gauge needle enters into the red band
indicated on the gauge dial.
Approximately 1 litre of petrol will be available in the
tank when the needle is in ‘RED’ band of speedometer
dial. Approximately 4.0 litres of petrol will be available
in the tank when the needle is in ‘F’ position.
2. Turn signal indicator lamp left
Turn signal indicator lamp left flashes when the turn
signal lamp switch knob is pushed to the left.
3. Speedometer
Indicates vehicle speed in kilometers per hour.
4. Odometer
Registers the total distance covered by the vehicle in
kilometers. The last digit denotes one tenth of a
kilometer.
5. High beam indicator lamp
When the head lamp high beam is ‘ON’, a blue high
Speedometer Assembly For WEGO Drum & Disc Version

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TVS WEGO 110 and is the answer not in the manual?

TVS WEGO 110 Specifications

General IconGeneral
Engine Capacity109.7 cc
Front BrakeDrum
Rear BrakeDrum
Wheel TypeAlloy
Kerb Weight108 kg
Seat Height770 mm
Front SuspensionTelescopic
Starting MethodKick & Electric Start
Tyre Type (Front)Tubeless
Tyre Type (Rear)Tubeless
Wheel Size (Front)12 inch
Wheel Size (Rear)12 inch
Ground Clearance150 mm
Engine Type4-stroke, Single-cylinder, Air-cooled
Fuel Tank Capacity5 liters
Rear SuspensionUnit Swing
TransmissionCVT
