44
MAINTENANCE
MAINTENANCE
3. If the brake fluid level is below the mark or while
applying brake if you feel the brake is more
spongy or ineffective due to air entry, contact TVS
Motor Company Authorised Main Dealer or
Authorised Dealer for topping-up the brake fluid,
air bleeding and other brake related inspections.
Brake pad wear indicator (Disc brake)
Check for the wear of brake pads visually. if found
beyond the wear indicator groove as shown in the
figure then, replace the brake pads as a set with a new
one.
Rear brake
1. Measure the free play of the rear brake lever at
the lever end as shown in the figure.
2. The free play of the brake lever before the
engagement of brake should be between 15
~ 20 mm.
15 ~ 20 mm
3. If the measured distance is more than the limit,
adjust the nut provided at the rear wheel end to
obtain the correct play.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TVS WEGO 110 and is the answer not in the manual?

TVS WEGO 110 Specifications

General IconGeneral
Engine Capacity109.7 cc
Front BrakeDrum
Rear BrakeDrum
Wheel TypeAlloy
Kerb Weight108 kg
Seat Height770 mm
Front SuspensionTelescopic
Starting MethodKick & Electric Start
Tyre Type (Front)Tubeless
Tyre Type (Rear)Tubeless
Wheel Size (Front)12 inch
Wheel Size (Rear)12 inch
Ground Clearance150 mm
Engine Type4-stroke, Single-cylinder, Air-cooled
Fuel Tank Capacity5 liters
Rear SuspensionUnit Swing
TransmissionCVT
