M8252T75-L24-1F
M8252T75-L24-1F Riser Card
PCB Dimensions:
 76.81mm x 270.04mm, thickness 1.6mm
Layer:
 12 layers
Features
 Support (1) PCIE Gen4 slots
PCIE x16 slot x1
M8252T75-R24-2F
M8252T75-R24-2F Riser Card
PCB Dimensions:
 76.81mm x 270.04mm, thickness 1.6mm
Layer:
 12 layers
Features
 Support (2) PCIE Gen4 slots
PCIE x16 slot x1/ PCIE x8 slot x1
