Motherboard Components
Connectors
1. Rear IO ID LED Button(IDLED_BTN1)
32. SSI 8-pin Power Connector (PE_PW2)
2. NMI Button(NMI_BTN1)
33. NVME Hot plug Header (J26)
3. Power Button (PWR_BTN1)
34. Slim SAS CON(SATA/PCIE) (J12)
4. Reset Button (COLD_RST_BTN1)
35. Slim SAS CON(SATA/PCIE) (J34)
5. NGFF 22x80mm Connector x2(NGFF1)
36. CPU0_FAN (CPU0_FAN)
6. NGFF 22x80mm Connector x2(NGFF2)
37. SYS_FAN_6 (SYS_FAN_6)
7. BMC Log Connector (J57)
38. Slim SAS CON(PCIE) (Slim SAS2)
8. VGA Port (VGA1)
39. SYS_FAN_5 (SYS_FAN_5)
9. X550 LAN Connector (X550_LAN2)
40. Slim SAS CON(PCIE) (Slim SAS1)
10. X550 LAN Connector(X550_LAN1)
41. SYS_FAN_4 (SYS_FAN_4)
11. CPLD Flash FW(JTAG1)
42. SYS_FAN_3 (SYS_FAN_3)
12. TYAN Module Header (DBG_HD1)
43. Slim SAS CON(PCIE) (Slim SAS3)
13. IPMI LAN Connector(BMC_LAN)
44. Slim SAS CON(PCIE) (Slim SAS4)
14. USB3.0 x2 (USB3_2)
45. SYS_FAN_2 (SYS_FAN_2)
15. USB3.0 x2 (USB3_1)
46. SYS_FAN_1 (SYS_FAN_1)
16. COM2/5 Header(COM2)
47. Vertical Type A USB
Connector(TYPEA_USB1)
17. COM1 Header (COM1)
48. P1_SATA_SGPIO1
(P1_SATA_SGPIO1)
18. 4-pin Power Connector (SHD_PW7)
49. NVME Hot plug Header (J25)
19. 4-pin Power Connector (SHD_PW8)
50. NVME Hot plug Header (J20)
20. P0_SATA_SGPIO0 (P0_SATA_SGPIO0)
51. SSI 8-pin Power Connector (PE_PW5)
21. P0_SATA_SGPIO1 (P0_SATA_SGPIO1)
52. CPU1_FAN (CPU1_FAN)
22. RPS Connector x2 (PSU1)
53. Slim SAS CON(SATA/PCIE) (J56)
23. Support SATADOM Connector x2
(SATADOM1)
54. 4-pin Power Connector (SHD_PW4)
24. Support SATADOM Connector x2
(SATADOM2)
55. SSI 8-pin Power Connector (PE_PW3)
25. SATA Connector x2 (SATA4)
56. Front Panel Pin Header (FPIO_2)
26. SATA Connector x2 (SATA3)
57. 8-pin Power Connector (HD_PW2)
27. SSI 8-pin Power Connector (PE_PW4)
58. 8-pin Power Connector (HD_PW1)
28. SYS_FAN Header (FAN_HD1)
59. RPS Connector x2 (PSU2)
29. SSI 8-pin Power Connector (PE_PW1)
60. 4-pin Power Connector (HD_PW3)
30. FPB USB2.0/USB3.0 *2 (USB3_FPIO1)
61. 4-pin Power Connector (SHD_PW6)
31. NVME Hot plug Header (J27)
62. 4-pin Power Connector (SHD_PW5)
Jumpers
a. BMC/CPU UART Change(J198)
g. SGPIO/SMBUS Change(J52)
b. BMC/CPU UART Change(J199)
h. SGPIO/SMBUS Change(J53)
c. COM2/5 Change (J201)
i. Disable SMBUS5 For CPU1 VR (J69)
