93
http://www.tyan.com
d. COM2/5 Change (J201)
j. Disable SMBUS5 For CPU1 VR (J68)
e. Clear COMS Jumper (J64)
k. Update Power VR FW (PJ1)
f. SGPIO/SMBUS Change(J51)
PCIE Slots
A. PCIE4.0 Slot x16 (J24)
D. PCIE4.0 Slot x24 （J21）
B. OCP 3.0 Slot (OCP3_0)
E. PCIE4.0 Slot x16 （J22）
C. PCIE4.0 Slot x24 （J23）
LEDs
i. IPMI Alert LED (IPMI_LED2)
x. CPLD CONF LED (LED3)
ii. PSU Alert LED (PSU_Alert1)
xi. P1 PROCHOT LED (LED11)
III.OCP PWR GOOD LED (LED13)
xii.P0 PROCHOT LED (LED4)
Iv. PSU PWROK LED (LED13)
xiii.PWR GOOD LED(LED5)
v.M.2 LED(LED_M1)
xiv. Reset LED (LED10)
vi.M.2 LED(LED_M2)
xv. SATA ACT LED (LED6)
vii.BMC Heartbeat LED(BMC_HBLED)
xvi. SATA ACT LED (LED7)
Viii CPLD STATUS LED(LED2)
xvii. SATA ACT LED (LED8)
ix. CPLD RCR ERROR LED(LED1)
xviii. SATA ACT LED (LED9)
Jumper Legend
OPEN - Jumper OFF
Without jumper cover
CLOSED - Jumper ON
With jumper cover
