USB3_FPIO1: Front USB2.0/USB3.0 *2 Header
Signal
Pin
Pin
Signal
+5V
1
20
KEY
P0_RX_N
2
19
+5V
P0_RX_P
3
18
P1_RX_N
GND
4
17
P1_RX_P
P0_TX_N
5
16
GND
P0_TX_P
6
15
P1_TX_N
GND
7
14
P1_TX_P
P0_N
8
13
GND
P0_P
9
12
P1_N
OC_N
10
11
P1_P
TYPEA_USB3: Vertical Type-A USB3.0 Connector
Signal
Pin
Pin
Signal
SSRX-
5
1
+5V
SSRX+
6
2
USB DATA2-
GND
7
3
USB DATA2+
SSTX-
8
4
GND
SSTX+
9
SGPIO Header (P0_SATA_SGPIO0/ P0_SATA_SGPIO1/ P1_SATA_SGPIO1)
Signal
Pin
Pin
Signal
CLK
1
2
SDIN
DATA
3
4
SDOUT
GND
5
6
SLOAD
NC
7
8
SCLOCK
VDD3_DUAL
9
10
NA
DBG_HD1: TYAN Module Header
Signal
Pin
Pin
Signal
P3V3
1
2
FRAME_N
LAD0
3
4
KEY
LAD1
5
6
PLT_RST_N
LAD2
7
8
GND
LAD3
9
10
CLK_33M
DBG_SERIRQ
11
12
GND
DBG_PRES_N
13
14
VCC3_AUX
TPM_ADDR_MB
15
16
PCH_TPM_PP_EN
