TYM ET350 ECONO - Page 29

22
Fig.4-2 Tractor controls
10. Electricity lock 11. Horn button 12. Decompression handle 13. Brake pedal RH
14. Lock plate 15. Foot throttle 16. Draft control 17. Brake pedal LH
18. Brake pawl 19. Main gear shift lever 20. Range gear-shift lever 21. Clutch pedal
22. Shut-off pull rod 23. Front head light switch 24. Tail light switch 25. Steering pilot lamp switch
26. Throttle handle
21
20 19 17 13
11
10
26
23
24
25
4
5
1418
12
