DESCRIPTION OF TRACTOR CONTROLS
1
2
2 - 29
O P E R AT I N G T I P S F O R
POWER STEERING WHEEL
(1) Oper ate th e powe r stee r ing
wheel only while the engine is
running. You may feel the steer-
ing wheel heavier with a low en-
gine speed.
(2) When an implement, such as a
loader, is attached to the front,
the steering wheel may be felt
heavy with the tractor stopped.
If so, operate the steering wheel
while driving the tractor at a low
speed.
(3) When the st e e r i n g w h e e l is
completely turned to one end,
the safety valve is activated to
output the audible signal (relief
sound). When this sounds, avoid
using the steering wheel (O.K.
only for a short time). Also, never
turn the steering wheel com-
pletely continuously.
►
IMPLEMENT LIFT CONTROL
SYSTEM
(1) Position lever
This lever is used to lift and lower
an implement to a certain working
height freely and maintain it.
<Operation>
「 Lifting implement」
Pull the lever back to lift the im-
plement.
「Lowering implement」
Push the lever forward to lower
the implement.
►
45NO239A
Position lever
(4) Turning the steering wheel to
its end unnecessarily (with the
tractor stopped) can wear tires
rapidly.
(5) In winter, warm up the engine
sufficiently before use.
(6)
When repairing components,
such as a pipe, make sure that
no foreign material enters the
system.
(7)
The steering wheel can be op-
erated with a small amount of
force. Therefore, operate it with
care and keep your hands on it
at all times.
Releasing the steering wheel
during driving can result in a
collision and rollover. Never re-
lease the steering wheel during
driving.
•
WARNING
To Next Page
