15
3 3.1 – 4.0 4000
4 4.1 - 6.0 3500
5 6.1 - 8.0 3000
Max. sewing speed according max zigzag pitch length
No. Max.feed pitch length(mm) Max.Speed(spm)
1 0 5000
2 0.1 – 2.0 3500
3 2.1 - 3.0 3000
4 3.1 - 4.0 2500
5 4.1 - 5.0 2000
2.11 Start Condensation Operation
Panel section concerned with start condensation setting is as below.
■ Operation Steps
1) Press “Start condensation” key in the normal state, the indicator nearby
the key will be lit up. The main display will show the number of
condensation stitches in the “A” side. Such as “A-**”
2) Press “Start condensation” key for sencond time, the main display will
show the number of condensation stitches in the “B” side. Such as
“b-**”.
3) Press “Start condensation” key for third time, the main display will show
the width of condensation stitches. Such as “U-**”.The data range is
0.0~8.0mm.If you press “Start condensation” key for fourth time, then
the start condensation operation will be cancelled and the indicator for
start condensation is off and the indicator for pattern width is lit up. Then
reverse feed disp normal feed disp.
rev. feed switch
Indicator for B and C side
Indicator for A and D side
