5 Setting the System Parameter
User can solve some sewing faults or adjust the sewing to the optimum condition
by use system parameter setting.
5.1 The list of the System Parameter
Parameter
Items
Function Description Range Default value Unit Remark
P-01 Max. sewing speed 100~5000 5000 spm
P-02 Half stitch speed 100~600 200 spm
P-03 Max.zigzag width 0.0~8.0 8.0 mm
P-04 Max feed pitch 0.0~5.0 5.0 mm
P-05 Zigzag origin offset -4.0~4.0 0 mm
P-06 Feed origin offset -2.5~2.5 0 mm
P-07 Sewing speed while
trimming
100~500 200 spm
P-08 Latency time after
trimmer
4~100 4 ms
P-09 Open angle of the thread
trimmer
0~180 30 °
P-10 Close angle of the thread
wiper
0~360 210 °
P-11 Close angle of the thread
trimmer
0~360 350 °
P-12 Presser foot auto-fall time 1~60 30 s
P-13 Latency time before
presser foot rise
4~500 200 ms
P-14 Latency time before
presser foot fall
4~500 100 ms
P-15 Total period of solenoids
control
1~9999 200 0.05us
P-16 Turn-on time of trimmer
solenoid control
1~9999 200 0.05us
P-17 Turn-on time of wiper
solenoid control
1~9999 200 0.05us
P-18 Turn-on time1 of foot
solenoid control
1~9999 200 0.05us
P-19 Turn-on time2 of foot
solenoid control
1~9999 90 0.05us
