typical GT856D - Power Specification; Change the Fuse

7
The list of the J3 Interface Signal
Signal No. No. Signal
5 1 Red（A+）
6 2 Green（A－）
7 3 Yellow（B+）
8 4 Blue（B－）
10 .Foot-lifting Solenoid Interface (J9)
This interface is use to connect to the solenoid which is used to lift the foot.
The list of the J9 Interface Signal
Signal No. No. signal
3 1
Foot Lift solenoid 4 2 Foot Lift solenoid
1.3 Power Specification
Power Voltage: Signal Phase 220V±20％
Supply Current: Average Current is lower than 3 A. Peak Current is lower than 7 A
1.4 Change the Fuse
There are 3 piece fuses on the main control board.
The Capacity and the Usage of the Fuse:
No. Capacity Usage
FP1 10A Protect the Main AC Power
FP2 10A Protect the step motor driver
FP4 10A Protect the Solenoids
In order to avoid the electric shock,When you open the chassis cover,please make sure
to cut off the power and wait 3 minutes at least.
