typical GT856D - External Interface of the Control Box

4
1.2 External Interface of the Control Box
RS232 Interface
Operation Panel Interface
Sensor Interface
Servo Motor Encoder Interface
Solenoid Interface
Servo Motor Interface
Zigzag Motor Interface
Feed Motor Interface
Foot lift Solenoid Interface
Control box Power Line
J8
J7
J6
J5
J4
J1
J2
J3
J9
