10. 3 DISASSEMBLING THE WATER COLLECTION TRAY
1 Remove the advertising picture at the rear by prising it off with a screwdriver inserted in the purpose-provided slot. Loosen the
fastening screw and pull the water collection tray out.
10. 4 DISASSEMBLING THE GEARED MOTOR
1 Remove the rear cover after loosening its fastening screws.
2 Loosen the fastening nuts on the geared motor and remove the latter from its seat.
