Ultimaker 2+ Manual

Ver. 01NL okt19
11
MAKERS LAB
Benno Premselahuis
Rhijnspoorplein 1
1091
GC Amsterdam
Wait until the material leaving the
nozzle is the same colour as the
material that was introduced.
Select READY and press the
button.
Select ‘Return’ and press it twice.
You have now returned to the Start
menu.

Ultimaker 2+ Specifications

General

Build Volume	223 x 223 x 205 mm
Layer Resolution	20 - 200 microns
Print Technology	Fused Filament Fabrication (FFF)
Filament Diameter	2.85 mm
Print Speed	30 - 300 mm/s
Connectivity	USB, SD Card
Weight	11.3 kg
Nozzle Diameter	0.4 mm
Supported Materials	PLA, ABS, CPE
Display	LCD
Software	Cura
Power Supply	100 - 240 VAC, 50 - 60 Hz
Operating Temperature	15 - 32 °C
Dimensions	342 x 588 mm
