Air Manager and Material Station
1. Cover
2. Filter housing
3. Filter
4. Handle
5. Stress relief
6. Mounting bracket
7. Fan
8. Hinge
9. Air Manager cable
10. UMB OUT port
1
7 8
2 3
4 91056
1. Glass door
2. Material bay
3. Filament entry ports 1(top) and 2 (bottom)
4. Eject button
5. UMB IN port
6. UMB OUT port
7. Dehumidier exhaust
8. Decoupler
9. Power entry
1 5 6 7 82
3 94
