Reassembly
1. Take the new Bowden tubes and note the two dierent sides. The side which is chamfered should be inserted
into the feeder. This allows easier access of the lament into the Bowden tube. The at side should be
inserted into the print head
2. Move the Bowden tubes through the slots in the mounting bracket of the Air Manager from the top
Above feeder 2, the Bowden tube should be placed in front of the print head cable.
3. Push the Bowden tubes all the way into the tube coupling collets of the feeders and print head. Secure the
tubes with the clamp clips
4. Click the four cable clips of the print head onto Bowden tube 2 and divide equally
5. Close the cover of the Air Manager
5.15 Clean the fans
System fans
The system fans are positioned at the back of the Ultimaker S5 and need to be cleaned once every year.
This can be done by blowing into the fans in order to get small lament particles out. If necessary, an air blower or
compressor can be used instead.
Air Manager fan
The fan in the Air Manager should be inspected once every year for dust and dirt. If the fan shows dust, this can be
removed with a soft brush. Remove any dirt with a damp microber cloth.
Ensure the Ultimaker S5 is turned o when cleaning the fan.
5.16 Lubricate the hinges
To make sure the glass doors will open and close smoothly, the hinges of the glass doors must be lubricated once a
year. This can be done by placing a small drop of oil in the top hole of each hinge.
The hinges of the Air Manager cover and the Material Station door do not require any maintenance.
5.17 Replace the Air Manager lter
The lter in the Air Manager is a consumable. It should be replaced every 1500 printing hours to maintain proper
ltering. The printer keeps track of the lter usage time and will alert you when replacement is due.
To replace the lter in the Air Manager, navigate to Preferences → Maintenance → Air Manager → Replace and follow
the steps on the touchscreen:
The function of the Air Manager’s lter is to reduce the emission of ultrane particles. These particles will
remain in the lter. The used lter should be handled with care during the replacement procedure. If the used
lter is not properly handled, there is a risk of the ultrane particles being released.
