Ultimaker S5 Pro Bundle user manual 11
Ultimaker S5
1. Glass doors
2. Print head
3. Build plate
4. Build plate clamps
5. Touchscreen
6. USB port
7. Feeder 2
8. Bowden tubes
9. Feeder 1
10. Power socket and switch
11. Ethernet port
12. Double spoolholder with NFC cable*
13. NFC socket
* Not used in the full Ultimaker S5 Pro Bundle
1
10111213
56
2 3 7
8
94
