Ultraframe Classic roof - Table of Contents

2
The core of the guide shows how to install a typical Georgian with Jack Rafters and glazed with glass.
section 1 Pre-installation checks 4
section 2 Roof vent sash 5
section 3 Main assemblies - overview 6-7
section 4 Georgian roof installation 8-21
section 5 Speedlok removal sequence 21-22
section 6 Slimline Ridge 22-24
section 7 Tie bars 24-25
section 8 Box gutter installation 26-27
Box gutter jointing 27
Box gutter support 28
Box gutter raised back 28-29
Chambered box gutter 30
section 9 Valleys 30-32
section 10 Half ridge installation 32
section 11 Ventilated wallplate installation 33
section 12 Gable installation 34-35
section 13 Drop valley installation 36
section 14 Bolstered glazing bars 37
section 15 Muntin bar installation 37
section 16 Tie Bar Replacement Kit (TBRK) 38-39
section 17 WOK 40
section 18 Lantern 40-41
section 19 Pagoda 41-42
section 20 Eaves beam - Super Duty, Bi-fold Support, 43
Super Bolster & Combination
section 21 Inter-rafter 44
section 22 L Shape ridges/half ridges 44-47
section 23 Conservaash 48
section 24 Roof vent installation 49-51
ALL box gutters (especially those
with tie bars or joints) MUST be
supported.
We recommend several types of
support for box gutters including
brick piers. See pages 24-25 for
details of our solutions. Fitting a
conservatory box gutter without
adequate support will lead to
structural failure. Please take the
correct steps BEFORE installation.
CONTENTS
Thank you for choosing the Classic system.
This guide is designed to make tting as straightforward as possible.
Before you commence installation of the roof, please;
1) Take a moment to read these two introductory pages before
reading the rest of this guide.
2) Donotxtheframesdownatthisstage–onlytemporarily‘pin’
theframestothehousewall(onexingeachside)toallowthe
conservatoryto‘oat’.
Ultraframe is rightly proud of its Classic roof. Over 1½ million
Classic roofs have been successfully installed over a 30 year
period. We have continued to invest to improve the features that
the homeowner will appreciate and that should make your life
easier. Any feedback - positive or negative - is welcomed so we
can make our systems even better.
Please contact the Tech Support Team
on
01200 452918 or email
techsupport@ultraframe.co.uk
