Ultraframe Classic roof - SECTION 8 BOX GUTTER SUPPORT; BOX GUTTER SUPPORT SYSTEMS; RAISED BACK BOX GUTTERS

28
BOX GUTTER SUPPORT
165mm box gutters
ThesearesuppliedlooseandMUSTBEFITTED–theyareastructuralrequirementofthe
roof. The straps must be installed within 75mm of glazing bar centres ( when measured
from centre of the strap to the centre of the bar). To install these straps, simply `nip up`
as shown.
265mm/special box gutters
Straps are factory welded into position.
BOX GUTTER STRAP
These are available for 165/265 box gutters.
To install, notch out the insulation to ensure metal to metal contact between the extruded
boxgutterandgallowsbracket.Oerupthegallowsbracketandmarkitreadytodrill–
always try to line up with the centre of a brick rather than a mortar joint. Drill the gallows
bracket ( the positions should be similar to the ones shown). Three masonry anchors
should be used that are appropriate to the substrate.
Finally,notchouttheundercladding,oeritintopositionandclipin.
Maximum centres are 2300mm. If the roof has a tie bar installed or a joint within the
box gutter, then a gallows bracket should be installed directly underneath it.
GALLOWS BRACKET
SECTION 8
165mm box gutters
Ifthesehavebeenspeciedbyyourcompanyatthetimeofordertheyaresuppliedloose
andmustbetted.
The structural requirement for the hanging brackets are 2 x hanging brackets (sat
side by side) at a maximum span of 2300mm unless the roof has a tie bar or joint on
the boxgutter which should then be positioned in the same area.
Drill through the head of the hanger into the centre of the masonry, avoiding the mortar
jointifpossible.Useamasonryanchorsuitableforthesubstrate.Leadashingshouldbe
dressed down over the hanger, and snipped around the sloped leg. To attach it to the box
gutter,simply‘nipup’asshown.
265mm box gutters
Hanger not avaialble.
BOX GUTTER HANGER
RAISED BACK BOX GUTTERS
SECTION 8
Oer the raised back or special box
gutter into position. Carefully mark onto
the aluminium leg against the host wall
the position of each xing – use 600mm
maximum centres.
1
Lift the box gutter down to the ground and
turn it around. Drill through the aluminium
leg (that abuts the host wall) at the pre-
marked positions. Whilst the box gutter is
on the ground, seal along the front/rear face
where the deep skirt sits inside the head of
the extruded box gutter. (Highlighted in red)
2
Lift the box gutter back into position, check
levels, and then mark the wall (through the
pre-drilled holes) ready to drill the host wall
andgrindoutfortheashing.
3
