GABLE INSTALLATION
SECTION 12
Place and support the ridge ensuring the
ridge is central to the gable frame. Place
the starter bar onto the rring top cap
and secure to the ridge and eaves beam.
Securely x the starter bars to the gable
window frame. Fit and glaze the roof in the
normal manner. NOTE: Ensure the gable
frame is vertically plumb.
10
Fit the starter bar top
capping in position.
11
Take the gable end cap - notch if
required for 70mm frames. Seal the
ridge body as shown.
12
Using plastic pop rivets
supplied, drill as shown
and install rivets - avoid
‘attop’ofprole
13
Follow same proceed-
ure on half ridge gable
ends.
14
Oertheleantocloakingtrim
up to the side of the gable
ridge end cap and scribe to
suittheroofpitch–pushinto
place against the end cap.
15
Notch for 70mm
frames
The overall length of the lean to cloaking
trim is to the end of the starter bar. Cut
in-line with the end of the starter bar.
The tapered cut along the lower edge
runs parallel with and along the gable
beam top cladding.
16
Finallytthestarterbarendcap.
