Ultraframe Classic roof - Eaves Assembly Options

7
MAIN ASSEMBLIES
Valley Section
SECTION 3
Eaves Assembly Options
Standard Eaves Beam Super Duty Eaves Beam
Internal
Frame/Setout

Eaves beam packer to suit roof
pitches5°,10°,35°and40°
5°packer

10°packer
35°packer
40°packer



For all eaves beam details e.g. bi fold support, super
bolster and combination, see page 43.
