9. Main Displacement Parts
Table. 7 Main displacement parts list
Part name Location PMB-040C PMB-060C Material
Bearing
(*1)
Pulley side 2 2 SUJ2
Bearing
(*1)
Gear side 2 2 SUJ2
Spacer Bearing case 1set 1set SUS
Mechanical seal Mechanical seal 1 1 -
Lip seal Shaft 4 4 PTFE
Shaft sleeve Shaft 4 4 S45C
O-ring
(*2)
G175 Bearing case 4 4 Fluor rubber
O-ring
(*2)
G110 Mechanical seal 1 1 Fluor rubber
O-ring Gs465 Side cover 2 2 Fluor rubber
O-ring
(*2)
G85 Shaft 8 8 Fluor rubber
O-ring
(*2)
P22.4 Filler port, drain port 4 4 Fluor rubber
O-ring
(*2)
G90 Oil level gauge 2 2 Fluor rubber
O-ring
(*2)
V275 Inlet port 1 － Fluor rubber
O-ring
(*2)
V325 Inlet port － 1 Fluor rubber
Oil level gauge (with gasket) Cover for pulley side 2 2 Glass
*1: The model depends on the production timing. Confirm the serial number (e.g. 1-40001/1-60001) and contact the
nearest sales office or agency.
*2: JIS standard
