YK15-0009-DI-002-04
5
Table. 2 Details model list
*1 There is not any naming for standard spec. Spec. F, N, B or H is selectable as option.
Options for pump head and accessories are different depending on the type.
*2 Multiple voltage motor is not available in the case of explosion-protection and flame-proof
motor. Voltage needs to be specified.
Optional specification for special application
Following specification is available to meet various applications.
Table. 3 Optional specifications and gasket material/oil type comparison table
Specification
Applicable Model
O-ring
Oil seal
Oil type *1
VD30C
VD40C
VD60C
VD90C
Wetted
surface
Atmosphere
side
Standard FKM FKM FKM ULVOIL R-72
Spec. F FKM FKM FKM BARRIERTA J60F
Spec. N n/a NBR NBR NBR ULVOIL R-72
Spec. B n/a Silicon rubber Silicon rubber NBR ULVOIL R-72
Spec. H FKM FKM FKM ULVOIL R-72
*1 ULVOIL R-72 stands for mineral oil, BARRIERTA J60F stands for fluorine oil.
