UXPW 125 ENGINE SERVICE MANUAL AND EFI DIAGNOSTIC
- 102 -
8.9.9. Install pressing pin body and pressing pin
body spring.
Note
Tapered face of pressing pin body shall
contact bearing.
8.9.10. Apply adhesive to thread on 2/3 of length,
then install pressing pin body guard and bolts
onto crankshaft case. Tighten the bolts to
specified value.
Tightening torque: 10N.m
8.9.11. Install chain, tension plate, chain guard plate,
in this order, then tighten bolts.
