UXPW 125 ENGINE SERVICE MANUAL AND EFI DIAGNOSTIC
- 105 -
main screen when the app has been
installed successfully.
Note:
To installation of Android version, Searching iOBD2 on Google play, download the app
and install.
9.2.2. Installation to OBD II port
Plug the iOBD2 adapter into the OBD II
port on the motorcycle and turn the
ignition switch on without starting the
engine. The OBD II port is located below
the front seat, but it may be variance on
different motorcycle models.
Image shows:
A. the OBD II location below the seat and
connection.
B. iOBD2 adapter
C. Right conection between OBD II and
iOBD2
9.2.3. Open the app
• Click
to open the iOBD2 application, the
interface of the app must appear.
