UXPW 125 ENGINE SERVICE MANUAL AND EFI DIAGNOSTIC
- 71 -
6.8.2.4. Align keyway on drive gear with
woodruff key on crankshaft and
assemble them. Apply appropriate
amount of engine oil on gears.
6.8.2.5. Assemble washer, locknut of drive
gear.
6.8.2.6. Tighten nut to specified torque;
Tightening torque: 64N.m
6.8.3. Balancing driven gear extraction
6.8.3.1. Dismantle locknut and washer.
