UTD2000 Series User Manual
44
Create According to adjustment, build horizontal and vertical Pass/Fail tolerance range.
Horizontal 1-200Pixel Press F2 to select horizontal length and use the multi-purpose knob to set the
pixel length for the horizontal length;
Vertical 1-100Pixel Press F3 to select vertical length and use the multi-purpose knob to set the pixel
length for the vertical length;
Return Return to pass detection menu
Back Return to Utility function menu
10.2 Recorder
The waveform recorder function at the UTD2000 series DSO is generally easy to
operate. User should set up Source and Operation as in below table.
Table 10-6 Recorder menu
Function Menu Setting Description
Source
CH1 Select CH1 as recording signal source
CH2 Select CH2 as recording signal source
CH1+CH2 Select CH1and CH2 as recording signal sources
Operation
●
Press to start waveform recording;
The number waveform being recorded is show on the screen.
Press to start waveform replay
■
Press to stop waveform recording
Save 1~200
Save waveform recording into USB memory; Select from 1-200 memory location;
Press F3 to save.
Load 1~200
Loadthewaveform recording into USB memory; Select from 1-200 memory
location; Press F4 to load.
Back Press to return to Utility function menu
You will need to press F1 to confirm creating the pixel template after setting the
horizontal and vertical length of the pixels.
To Next Page
