98 UTG2000B Series
Figure 3 -42 Set frequency sweep parameters
You can set with multi-functional knob and direction key. You can also press corresponding soft
function keys again, when the interface below will pop up. To set some parameter, press Param ,
input the required value and select the unit.
Figure 3 - 43 Set trigger frequency
4) Enable channel output
Press CH1 button start channel 1 output quickly. Or enable output by pressing Utility and then CH1
Setting . After channel output is opened, backlight of CH1 button is on, and on the right side of
channel information label, the font “OFF” changes to “Line”, meaning open channel output.
