MAIN TRUCK - 1F2 (PNEUMATIC) BASED ON 2W330 MAST, 1070MM FORKS AND MINIMUM BATTERY SPECIFICATIONS
Model code
Item
1F2
MP1F2A20JV/
LV/DV
MU1F2A20JV/
LV/DV
MY1F2A20V/U MP1F2A20U/WU MU1F2A20U/WU
Rated Load Capacity lb (kg) Refer to Truck Data Plate
Load center in (mm) 24 (600)
Overall Length (to face of forks) in (mm) 96.9 (2460)
Overall Width (standard tires) in (mm) 45.3 (1150)
Wheelbase in (mm) 63.0 (1600)
Front Overhang in (mm) 17.5 (445)
Rear Overhang in (mm) 16.3 (415)
Tread - Center of Tire
(standard tires)
Front in (mm) 37.8 (960)
Rear in (mm) 38.4 (975)
Minimum Turning Radius Outside in (mm) 83.5 (2120)
Minimum Right Angle Stack
Add load length &
clearance
in (mm) 101.0 (2565)
Fork Length (standard) in (mm) 42.0 (1070)
Fork Width x Thickness in (mm) 1.5 x 4 (40 x 100)
Ground Clearance
Under Mast in (mm) 4.5 (115)
Under Power Unit in (mm) 5.3 (135)
Under Frame, center
of wheelbase
in (mm) 6.1 (155)
Gradeability Maximum
Full Load % 31.0 39.0 36.0 26.0 34.0
Empty % 28.0 Not Available
