43
Hour Meter
The buttons can be used to
change from the normal display
(clock) to the hour meter
display.
The hour meter ordinarily
displays the total ignition time
that the ignition is on, however
it is possible to change the
display to the total engine operating time. To change the hour meter
totaling pattern contact your Local Authorized Dealer.
11. WATER TEMPERATURE GAUGE
Indicates the current water
temperature in levels 0 - 4.
When level 2 is indicated, the
coolant temperature is correct.
When the indication reaches
level 4, the display begins to
blink, and the multipurpose
warning light illuminates to
inform the operator of the high
water temperature.
CAUTION
!
• If level 4 is indicated, stop the lift truck and allow the engine
to cool while idling. After the engine has sufciently cooled
down, turn the engine off and check the coolant level and fan
belt deection.
NOTE TO THE OPERATOR:
EFI lift trucks have a creep home feature that will reduce engine RPMs
if the coolant temperature remains near the "H" position. This indicates
that the lift truck should be serviced by your Local Authorized Dealer.
FR
C
E
H
F
N
08235.6
FR
C
E
H
F
N
10
:
25
Fuel gauge
Multipurpose warning lamp
Water temp. gauge
CH
CH
CH
CH
+
CH
Temp. Indication Level
Low
High
Level 4
Level 3
Level 2
Level 1
Level 0
