UniCarriers 1F1 - Switches; Horn Button; Rear Right Grip with Horn Button

52
SWITCHES
1. Horn button
2. Ignition switch
3. Lighting switch and Turn signal switch
NOTE:
For forklifts with the optional joystick control, this switch is located on
the left side.
4. Fuel change switch (Dual Fuel lift trucks)
5. Seat belt interlock or Shutdown indicator (red - option) (see page
55)
6. Maximum speed change switch (option) (see page 55)
7. Throttle sensitivity adjust switch (option) (see page 56)
8. Transmission shift (SmoothShift) indicator (green - option) (see page
56)
HORN BUTTON
Pushing the button in the center of the steering wheel will sound the
horn, regardless of ignition switch position.
NOTE:
For forklifts with the optional joystick control, there is also a horn button
located on the joystick control.
REAR RIGHT GRIP WITH HORN BUTTON
This button allows you to
honk the horn from the
grip on the rear right pillar.
1
2
3
8
7
6
5
4
