UniCarriers 1F1 - Page 155

153
Model code
Item
1F2
MUG1F2A35JV/LV/DV MYG1F2A35V/U MUG1F2A35U/WU
Maximum Travel Speed
Forward mph (km/h) 11.5 (18.5) 11.2 (18.0)
Reverse mph (km/h) 11.5 (18.5) 11.2 (18.0)
Drawbar Pull Maximum Full Load lb (kg / N) 4034 (1830 / 17950) 4056 (1840 / 18050) 4497 (2040 / 20005)
Truck Weight lb (kg) Refer to Truck Data Plate
Engine
Model K25, GK25 QD32 K25, GK25
Classication EFI
V = EFI
U = Carburetor
Carburetor
Rated Output -
SAE Gross
hp (kW) @
rpm
62.9 (46.9) @ 2700 55 (41) @ 2000 53.6 (40) @ 2200
Rated Torque - SAE
Gross
ft-lb (Nm) @
rpm
138.7 (188) @ 1600 143.8 (195) @ 1800 137.2 (186) @ 1600
Displacement cu in (cm) 151.8 (2488) 192.4 (3153) 151.8 (2488)
Transmission
Type Automatic
Number Speeds - fwd/rev 1/1
