156
Model code
Item
1F1
MCP1F1A15LV/DV MCP1F1A18LV/DV MCP1F1A20LV/DV
Maximum Travel Speed
Forward mph (km/h) 10.9 (17.5)
Reverse mph (km/h) 10.9 (17.5)
Drawbar Pull Maximum Full Load lb (kg / N) 3417 (1550 / 15200)
Truck Weight lb (kg) Refer to Truck Data Plate
Engine
Model K21, GK21
Classication EFI
Rated Output -
SAE Gross
hp (kW) @ rpm
55 (41) @ 2700
Rated Torque -
SAE Gross
ft-lb (Nm) @ rpm
111.4 (151) @ 2000
Displacement cu in (cm) 126 (2065)
Transmission
Type Automatic
Number Speeds - fwd/rev 1/1
