UniCarriers 1F1 - Page 161

159
Model code
Item
1F2
MCP1F2A20JV/LV/
DV
MCU1F2A20LV/DV
MCP1F2A25JV/LV/
DV
MCU1F2A25LV/DV
Maximum Travel Speed
Forward mph (km/h) 10.6 (17)
Reverse mph (km/h) 10.6 (17)
Drawbar Pull Maximum Full Load lb (kg / N) 3638 (1650 / 16180) 4189 (1900 / 18635) 3638 (1650 / 16180) 4189 (1900 / 18635)
Truck Weight lb (kg) Refer to Truck Data Plate
Engine
Model K21, GK21 K25, GK25 K21, GK21 K25, GK25
Classication EFI
Rated Output -
SAE Gross
hp (kW) @
rpm
55 (41) @ 2700 62.9 (46.9) @ 2700 55 (41) @ 2700 62.9 (46.9) @ 2700
Rated Torque - SAE
Gross
ft-lb (Nm) @
rpm
111.4 (151) @ 2000 138.7 (188) @ 1600 111.4 (151) @ 2000 138.7 (188) @ 1600
Displacement cu in (cm) 126 (2065) 151.8 (2488) 126 (2065) 151.8 (2488)
Transmission
Type Automatic
Number Speeds - fwd/rev 1/1
