UniCarriers 1F1 - Page 163

161
Model code
Item
1F2
MCP1F2A28JV/LV/
DV
MCU1F2A28LV/DV MCU1F2A30LV/DV MCUG1F2F30LV/DV
Grade Clearance
Approach Angle % 26.0 24.0
Ramp Breakover
Angle
% 42.0 44.0
Departure Angle % 28.0 27.0 35.0
Lifting Speed
2H
Full Load fpm (mm/sec) 94.5 (480) 104.3 (530)
Empty fpm (mm/sec) 102.4 (520) 110.2 (560)
2F
Full Load fpm (mm/sec) 92.5 (470) 102.4 (520)
Empty fpm (mm/sec) 100.4 (510) 112.2 (570)
3F
Full Load fpm (mm/sec) 90.6 (460) 100.4 (510)
Empty fpm (mm/sec) 98.4 (500) 110.2 (560)
3V
Full Load fpm (mm/sec) 90.6 (460) 100.4 (510)
Empty fpm (mm/sec) 98.4 (500) 110.2 (560)
Lowering Speed
2H
Full Load fpm (mm/sec) 98.4 (500)
Empty fpm (mm/sec) 98.4 (500)
2F
Full Load fpm (mm/sec) 92.5 (470)
Empty fpm (mm/sec) 63.0 (320)
3F
Full Load fpm (mm/sec) 92.5 (470)
Empty fpm (mm/sec) 70.9 (360)
3V
Full Load fpm (mm/sec) 92.5 (470)
Empty fpm (mm/sec) 70.9 (360)
