UniCarriers 1F1 - Mast - 1 F2 3.0 Ton (Pneumatic)

173
MAST - 1F2 2.8 TON (PNEUMATIC)
Mast Name
Maximum Fork Height
in (mm)
Free Lift
without
Backrest
in (mm)
Tilt Angle
Forward/Backward
Overall Height
Lowered Mast Position
in (mm)
Extended Mast Position
in (mm)
Top of OHG Mast (OHL) With Backrest Without Backrest
TWO STAGE
(Wide View 2W)
2W270 106 (2700) 6.1 (150) 6/12 84.6 (2150) 73.8 (1875) 155.7 (3955) 130.6 (3319)
2W300 118 (3000) 6.1 (150) 6/12 84.6 (2150) 79.7 (2025) 167.5 (4255) 142.5 (3619)
2W330 130 (3300) 6.1 (150) 6/12 84.6 (2150) 85.6 (2175) 179.3 (4555) 154.3 (3919)
2W350 138 (3500) 6.1 (150) 6/12 84.6 (2150) 90.9 (2310) 187.2 (4755) 162.1 (4119)
2W370 146 (3700) 6.1 (150) 6/12 84.6 (2150) 95.9 (2440) 195.1 (4955) 170.0 (4319)
2W400 157 (4000) 6.1 (150) 6/6 84.6 (2150) 103.3 (2625) 206.9 (5255) 181.8 (4619)
2W450 177 (4500) 6.1 (150) 6/6 84.6 (2150) 113.2 (2875) 226.6 (5755) 201.5 (5119)
2W500 197 (5000) 6.1 (150) 6/6 84.6 (2150) 123.0 (3125) 246.3 (6255) 221.2 (5619)
TWO STAGE
(Full Free 2F)
2F300 118 (3000) 53.8 (1365) 6/12 84.6 (2150) 79.7 (2025) Not Available
2F330 130 (3300) 59.7 (1515) 6/12 84.6 (2150) 85.6 (2175) Not Available
2F350 138 (3500) 65.1 (1650) 6/12 84.6 (2150) 90.9 (2310) Not Available
2F370 146 (3700) 70.0 (1775) 6/12 84.6 (2150) 95.9 (2440) Not Available
2F400 157 (4000) 77.5 (1965) 6/6 84.6 (2150) 103.3 (2625) Not Available
